OUTDOOR EURO HUMIDITY

OVERVIEW

High quality outdoor mounted Relative Humidity (RH) and Temperature (T) sensor in the NEMA 4X Euro enclosure, equipped with hinged cover and tool-free Quick Connect wire terminals.

Outdoor Euro humidity sensors are also equipped with an active analog temperature signal, with the option of an additional passive NTC or RTD element.

Tasseron Euro humidity sensors offer high accuracy and long term stability with minimal annual drift. Dual filters on the elements resist contamination and ensure reliability over time and coated circuit boards supply additional protection to the electronics

THHOEZ5A OUTDOOR EURO HUMIDITY 5% 4-20mA NO TEMP THHOEZ5C OUTDOOR EURO HUMIDITY 5% 0-10V NO TEMP THHOEZ3A OUTDOOR EURO HUMIDITY 3% 4-20mA NO TEMP THHOEZ3C OUTDOOR EURO HUMIDITY 3% 0-10V NO TEMP THHOEZ2A OUTDOOR EURO HUMIDITY 2% 4-20mA NO TEMP THHOEZ2C OUTDOOR EURO HUMIDITY 2% 0-10V NO TEMP THHOEW5A OUTDOOR EURO HUMIDITY 5% 4-20mA + TEMP (0..50C) THHOEW5C OUTDOOR EURO HUMIDITY 5% 0-10V + TEMP (0..50C) THHOEW3A OUTDOOR EURO HUMIDITY 3% 4-20mA + TEMP (0..50C) THHOEW3C OUTDOOR EURO HUMIDITY 3% 0-10V + TEMP (0..50C) THHOEW2A OUTDOOR EURO HUMIDITY 2% 4-20mA + TEMP (0..50C) THHOEW2C OUTDOOR EURO HUMIDITY 2% 0-10V + TEMP (0..50C) THHOEX5A OUTDOOR EURO HUMIDITY 5% 4-20mA + TEMP (-40..70C) THHOEX5C OUTDOOR EURO HUMIDITY 5% 0-10V + TEMP (-40..70C) THHOEX3A OUTDOOR EURO HUMIDITY 3% 4-20mA + TEMP (-40..70C) THHOEX3C OUTDOOR EURO HUMIDITY 3% 0-10V + TEMP (-40..70C) THHOEX2A OUTDOOR EURO HUMIDITY 2% 4-20mA + TEMP (-40..70C) THHOEX2C OUTDOOR EURO HUMIDITY 2% 0-10V + TEMP (-40..70C) THHOET5A OUTDOOR EURO HUMIDITY 5% 4-20mA + TEMP (0..100C / 32..212F) THHOET5C OUTDOOR EURO HUMIDITY 5% 0-10V + TEMP (0..100C / 32..212F) THHOET3A OUTDOOR EURO HUMIDITY 3% 4-20mA + TEMP (0..100C / 32..212F) THHOET3C OUTDOOR EURO HUMIDITY 3% 0-10V + TEMP (0..100C / 32..212F) THHOET2A OUTDOOR EURO HUMIDITY 2% 4-20mA + TEMP (0..100C / 32..212F) THHOET2C OUTDOOR EURO HUMIDITY 2% 0-10V + TEMP (0..100C / 32..212F) THHOEU5A OUTDOOR EURO HUMIDITY 5% 4-20mA + TEMP (20..120F) THHOEU5C OUTDOOR EURO HUMIDITY 5% 0-10V + TEMP (20..120F) THHOEU3A OUTDOOR EURO HUMIDITY 3% 4-20mA + TEMP (20..120F) THHOEU3C OUTDOOR EURO HUMIDITY 3% 0-10V + TEMP (20..120F) THHOEU2A OUTDOOR EURO HUMIDITY 2% 4-20mA + TEMP (20..120F) THHOEU2C OUTDOOR EURO HUMIDITY 2% 0-10V + TEMP (20..120F) THHOEV5A OUTDOOR EURO HUMIDITY 5% 4-20mA + TEMP (0..100F) THHOEV5C OUTDOOR EURO HUMIDITY 5% 0-10V + TEMP (0..100F) THHOEV3A OUTDOOR EURO HUMIDITY 3% 4-20mA + TEMP (0..100F) THHOEV3C OUTDOOR EURO HUMIDITY 3% 0-10V + TEMP (0..100F) THHOEV2A OUTDOOR EURO HUMIDITY 2% 4-20mA + TEMP (0..100F) THHOEV2C OUTDOOR EURO HUMIDITY 2% 0-10V + TEMP (0..100F) THHOEA5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 10K-2 TEMP THHOEA5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 10K-2 TEMP THHOEA3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 10K-2 TEMP THHOEA3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 10K-2 TEMP THHOEA2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 10K-2 TEMP THHOEA2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 10K-2 TEMP THHOEB5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 10K-3 TEMP THHOEB5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 10K-3 TEMP THHOEB3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 10K-3 TEMP THHOEB3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 10K-3 TEMP THHOEB2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 10K-3 TEMP THHOEB2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 10K-3 TEMP THHOEJ5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 10K-3[11K] TEMP THHOEJ5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 10K-3[11K] TEMP THHOEJ3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 10K-3[11K] TEMP THHOEJ3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 10K-3[11K] TEMP THHOEJ2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 10K-3[11K] TEMP THHOEJ2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 10K-3[11K] TEMP THHOEG5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 10K-4 TEMP THHOEG5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 10K-4 TEMP THHOEG3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 10K-4 TEMP THHOEG3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 10K-4 TEMP THHOEG2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 10K-4 TEMP THHOEG2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 10K-4 TEMP THHOEC5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 20K TEMP THHOEC5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 20K TEMP THHOEC3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 20K TEMP THHOEC3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 20K TEMP THHOEC2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 20K TEMP THHOEC2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 20K TEMP THHOED5A OUTDOOR EURO HUMIDITY 5% 4-20mA + NTC 3K TEMP THHOED5C OUTDOOR EURO HUMIDITY 5% 0-10V + NTC 3K TEMP THHOED3A OUTDOOR EURO HUMIDITY 3% 4-20mA + NTC 3K TEMP THHOED3C OUTDOOR EURO HUMIDITY 3% 0-10V + NTC 3K TEMP THHOED2A OUTDOOR EURO HUMIDITY 2% 4-20mA + NTC 3K TEMP THHOED2C OUTDOOR EURO HUMIDITY 2% 0-10V + NTC 3K TEMP THHOEE5A OUTDOOR EURO HUMIDITY 5% 4-20mA + RTD PT1000 TEMP THHOEE5C OUTDOOR EURO HUMIDITY 5% 0-10V + RTD PT1000 TEMP THHOEE3A OUTDOOR EURO HUMIDITY 3% 4-20mA + RTD PT1000 TEMP THHOEE3C OUTDOOR EURO HUMIDITY 3% 0-10V + RTD PT1000 TEMP THHOEE2A OUTDOOR EURO HUMIDITY 2% 4-20mA + RTD PT1000 TEMP THHOEE2C OUTDOOR EURO HUMIDITY 2% 0-10V + RTD PT1000 TEMP THHOEH5A OUTDOOR EURO HUMIDITY 5% 4-20mA + RTD PT100 TEMP THHOEH5C OUTDOOR EURO HUMIDITY 5% 0-10V + RTD PT100 TEMP THHOEH3A OUTDOOR EURO HUMIDITY 3% 4-20mA + RTD PT100 TEMP THHOEH3C OUTDOOR EURO HUMIDITY 3% 0-10V + RTD PT100 TEMP THHOEH2A OUTDOOR EURO HUMIDITY 2% 4-20mA + RTD PT100 TEMP THHOEH2C OUTDOOR EURO HUMIDITY 2% 0-10V + RTD PT100 TEMP THHOEF5A OUTDOOR EURO HUMIDITY 5% 4-20mA + RTD NI1000-891 TEMP THHOEF5C OUTDOOR EURO HUMIDITY 5% 0-10V + RTD NI1000-891 TEMP THHOEF3A OUTDOOR EURO HUMIDITY 3% 4-20mA + RTD NI1000-891 TEMP THHOEF3C OUTDOOR EURO HUMIDITY 3% 0-10V + RTD NI1000-891 TEMP THHOEF2A OUTDOOR EURO HUMIDITY 2% 4-20mA + RTD NI1000-891 TEMP THHOEF2C OUTDOOR EURO HUMIDITY 2% 0-10V + RTD NI1000-891 TEMP THHOEK5A OUTDOOR EURO HUMIDITY 5% 4-20mA + RTD NI1000-TC5 TEMP THHOEK5C OUTDOOR EURO HUMIDITY 5% 0-10V + RTD NI1000-TC5 TEMP THHOEK3A OUTDOOR EURO HUMIDITY 3% 4-20mA + RTD NI1000-TC5 TEMP THHOEK3C OUTDOOR EURO HUMIDITY 3% 0-10V + RTD NI1000-TC5 TEMP THHOEK2A OUTDOOR EURO HUMIDITY 2% 4-20mA + RTD NI1000-TC5 TEMP THHOEK2C OUTDOOR EURO HUMIDITY 2% 0-10V + RTD NI1000-TC5 TEMP THHOEY5D OUTDOOR EURO HUMIDITY 5% + TEMP MODBUS THHOEY3D OUTDOOR EURO HUMIDITY 3% + TEMP MODBUS THHOEY2D OUTDOOR EURO HUMIDITY 2% + TEMP MODBUS

FEATURES

  • Accurate humidity or temperature/humidity combination options

  • Durable NEMA 4X / IP65 injection-molded watertight enclosure

  • Dual filters to protect from contamination

  • 2% or 3% RH accuracy options available

  • Solar shield included for radiation protection and high air flow

  • Coated circuit boards for moisture resistance

  • Analog temperature with 0-10V output built-in

  • NTC or RTD elements available for passive temperature

  • Long term stability and low annual drift

  • Compatible with most control systems

  • Quick Connect wire terminals for tool-free wiring

  • CE & RoHS compliant

  • 5 year limited warranty

BUY NOW
BUY NOW
REQUEST A QUOTE
REQUEST A QUOTE
DATASHEET
DATASHEET
sell sheet
sell sheet

Instructions:

OUTDOOR EURO RH INSTALLATION INSTRUCTIONS

OUTDOOR SAFE HUMIDITY

Q-OUTDOOR SAFE HUMIDITY_more cropped.jpg

OVERVIEW

High quality outdoor rated relative humidity transmitter in the NEMA 4X / IP65 Safe Box enclosure. Coated circuit boards are treated to resist moisture and offer accurate measurement with long term stability.

Humidity sensors are also available with optional passive thermistors or RTDs for temperature measurement.

The hinged polycarbonate cover and quick connect wire terminals make installation easy and reduce installation costs.

THHOSZ5A OUTDOOR SAFE HUMIDITY 5% 4-20MA THHOSZ5B OUTDOOR SAFE HUMIDITY 5% 0-5V THHOSZ5C OUTDOOR SAFE HUMIDITY 5% 0-10V THHOSZ3A OUTDOOR SAFE HUMIDITY 3% 4-20MA THHOSZ3B OUTDOOR SAFE HUMIDITY 3% 0-5V THHOSZ3C OUTDOOR SAFE HUMIDITY 3% 0-10V THHOSZ2A OUTDOOR SAFE HUMIDITY 2% 4-20MA THHOSZ2B OUTDOOR SAFE HUMIDITY 2% 0-5V THHOSZ2C OUTDOOR SAFE HUMIDITY 2% 0-10V THHOSA5A OUTDOOR SAFE HUMIDITY 5% 10K TYPE 2 4-20MA THHOSA5B OUTDOOR SAFE HUMIDITY 5% 10K TYPE 2 0-5V THHOSA5C OUTDOOR SAFE HUMIDITY 5% 10K TYPE 2 0-10V THHOSA3A OUTDOOR SAFE HUMIDITY 3% 10K TYPE 2 4-20MA THHOSA3B OUTDOOR SAFE HUMIDITY 3% 10K TYPE 2 0-5V THHOSA3C OUTDOOR SAFE HUMIDITY 3% 10K TYPE 2 0-10V THHOSA2A OUTDOOR SAFE HUMIDITY 2% 10K TYPE 2 4-20MA THHOSA2B OUTDOOR SAFE HUMIDITY 2% 10K TYPE 2 0-5V THHOSA2C OUTDOOR SAFE HUMIDITY 2% 10K TYPE 2 0-10V THHOSB5A OUTDOOR SAFE HUMIDITY 5% 10K TYPE 3 4-20MA THHOSB5B OUTDOOR SAFE HUMIDITY 5% 10K TYPE 3 0-5V THHOSB5C OUTDOOR SAFE HUMIDITY 5% 10K TYPE 3 0-10V THHOSB3A OUTDOOR SAFE HUMIDITY 3% 10K TYPE 3 4-20MA THHOSB3B OUTDOOR SAFE HUMIDITY 3% 10K TYPE 3 0-5V THHOSB3C OUTDOOR SAFE HUMIDITY 3% 10K TYPE 3 0-10V THHOSB2A OUTDOOR SAFE HUMIDITY 2% 10K TYPE 3 4-20MA THHOSB2B OUTDOOR SAFE HUMIDITY 2% 10K TYPE 3 0-5V THHOSB2C OUTDOOR SAFE HUMIDITY 2% 10K TYPE 3 0-10V THHOSJ5A OUTDOOR SAFE HUMIDITY 5% 10K-3 [11K] SHUNT 4-20MA THHOSJ5B OUTDOOR SAFE HUMIDITY 5% 10K-3 [11K] SHUNT 0-5V THHOSJ5C OUTDOOR SAFE HUMIDITY 5% 10K-3 [11K] SHUNT 0-10V THHOSJ3A OUTDOOR SAFE HUMIDITY 3% 10K-3 [11K] SHUNT 4-20MA THHOSJ3B OUTDOOR SAFE HUMIDITY 3% 10K-3 [11K] SHUNT 0-5V THHOSJ3C OUTDOOR SAFE HUMIDITY 3% 10K-3 [11K] SHUNT 0-10V THHOSJ2A OUTDOOR SAFE HUMIDITY 2% 10K-3 [11K] SHUNT 4-20MA THHOSJ2B OUTDOOR SAFE HUMIDITY 2% 10K-3 [11K] SHUNT 0-5V THHOSJ2C OUTDOOR SAFE HUMIDITY 2% 10K-3 [11K] SHUNT 0-10V THHOSC5A OUTDOOR SAFE HUMIDITY 5% 20K 4-20MA THHOSC5B OUTDOOR SAFE HUMIDITY 5% 20K 0-5V THHOSC5C OUTDOOR SAFE HUMIDITY 5% 20K 0-10V THHOSC3A OUTDOOR SAFE HUMIDITY 3% 20K 4-20MA THHOSC3B OUTDOOR SAFE HUMIDITY 3% 20K 0-5V THHOSC3C OUTDOOR SAFE HUMIDITY 3% 20K 0-10V THHOSC2A OUTDOOR SAFE HUMIDITY 2% 20K 4-20MA THHOSC2B OUTDOOR SAFE HUMIDITY 2% 20K 0-5V THHOSC2C OUTDOOR SAFE HUMIDITY 2% 20K 0-10V THHOSD5A OUTDOOR SAFE HUMIDITY 5% 3K 4-20MA THHOSD5B OUTDOOR SAFE HUMIDITY 5% 3K 0-5V THHOSD5C OUTDOOR SAFE HUMIDITY 5% 3K 0-10V THHOSD3A OUTDOOR SAFE HUMIDITY 3% 3K 4-20MA THHOSD3B OUTDOOR SAFE HUMIDITY 3% 3K 0-5V THHOSD3C OUTDOOR SAFE HUMIDITY 3% 3K 0-10V THHOSD2A OUTDOOR SAFE HUMIDITY 2% 3K 4-20MA THHOSD2B OUTDOOR SAFE HUMIDITY 2% 3K 0-5V THHOSD2C OUTDOOR SAFE HUMIDITY 2% 3K 0-10V THHOSG3A OUTDOOR SAFE HUMIDITY 3% 10K-4 4-20MA THHOSG3B OUTDOOR SAFE HUMIDITY 3% 10K-4 0-5V THHOSG3C OUTDOOR SAFE HUMIDITY 3% 10K-4 0-10V THHOSG2A OUTDOOR SAFE HUMIDITY 2% 10K-4 4-20MA THHOSG2B OUTDOOR SAFE HUMIDITY 2% 10K-4 0-5V THHOSG2C OUTDOOR SAFE HUMIDITY 2% 10K-4 0-10V THHOSH5A OUTDOOR SAFE HUMIDITY 5% PT100 4-20MA THHOSH5B OUTDOOR SAFE HUMIDITY 5% PT100 0-5V THHOSH5C OUTDOOR SAFE HUMIDITY 5% PT100 0-10V THHOSH3A OUTDOOR SAFE HUMIDITY 3% PT100 4-20MA THHOSH3B OUTDOOR SAFE HUMIDITY 3% PT100 0-5V THHOSH3C OUTDOOR SAFE HUMIDITY 3% PT100 0-10V THHOSH2A OUTDOOR SAFE HUMIDITY 2% PT100 4-20MA THHOSH2B OUTDOOR SAFE HUMIDITY 2% PT100 0-5V THHOSH2C OUTDOOR SAFE HUMIDITY 2% PT100 0-10V THHOSE5A OUTDOOR SAFE HUMIDITY 5% PT1000 4-20MA THHOSE5B OUTDOOR SAFE HUMIDITY 5% PT1000 0-5V THHOSE5C OUTDOOR SAFE HUMIDITY 5% PT1000 0-10V THHOSE3A OUTDOOR SAFE HUMIDITY 3% PT1000 4-20MA THHOSE3B OUTDOOR SAFE HUMIDITY 3% PT1000 0-5V THHOSE3C OUTDOOR SAFE HUMIDITY 3% PT1000 0-10V THHOSE2A OUTDOOR SAFE HUMIDITY 2% PT1000 4-20MA THHOSE2B OUTDOOR SAFE HUMIDITY 2% PT1000 0-5V THHOSE2C OUTDOOR SAFE HUMIDITY 2% PT1000 0-10V THHOSF5A OUTDOOR SAFE HUMIDITY 5% NI1000-891 4-20MA THHOSF5B OUTDOOR SAFE HUMIDITY 5% NI1000-891 0-5V THHOSF5C OUTDOOR SAFE HUMIDITY 5% NI1000-891 0-10V THHOSF3A OUTDOOR SAFE HUMIDITY 3% NI1000-891 4-20MA THHOSF3B OUTDOOR SAFE HUMIDITY 3% NI1000-891 0-5V THHOSF3C OUTDOOR SAFE HUMIDITY 3% NI1000-891 0-10V THHOSF2A OUTDOOR SAFE HUMIDITY 2% NI1000-891 4-20MA THHOSF2B OUTDOOR SAFE HUMIDITY 2% NI1000-891 0-5V THHOSF2C OUTDOOR SAFE HUMIDITY 2% NI1000-891 0-10V THHOSK5A OUTDOOR SAFE HUMIDITY 5% NI1000-TC5 4-20MA THHOSK5B OUTDOOR SAFE HUMIDITY 5% NI1000-TC5 0-5V THHOSK5C OUTDOOR SAFE HUMIDITY 5% NI1000-TC5 0-10V THHOSK3A OUTDOOR SAFE HUMIDITY 3% NI1000-TC5 4-20MA THHOSK3B OUTDOOR SAFE HUMIDITY 3% NI1000-TC5 0-5V THHOSK3C OUTDOOR SAFE HUMIDITY 3% NI1000-TC5 0-10V THHOSK2A OUTDOOR SAFE HUMIDITY 2% NI1000-TC5 4-20MA THHOSK2B OUTDOOR SAFE HUMIDITY 2% NI1000-TC5 0-5V THHOSK2C OUTDOOR SAFE HUMIDITY 2% NI1000-TC5 0-10V

FEATURES

  • Humidity or temperature/humidity option

  • Durable NEMA 4X injection-molded watertight enclosure

  • Quick Connect wire terminals

  • Dual filters to protect from contamination

  • 2% / 3% /5% RH accuracies

  • On-board DIP switches for selecting output in the field (0-5V, 0-10V & 4-20mA)

  • Passive temperature with NTC or RTD elements

  • Coated circuit boards for moisture resistance

  • Compatible with most control systems

  • 1/2” NPT conduit adapter included

  • CE & RoHS compliant

  • 5 year limited warranty

BUY NOW
BUY NOW
REQUEST A QUOTE
REQUEST A QUOTE
Datasheet
Datasheet

Instructions:

HUMIDITY SENSORS INSTALLATION

HUMIDITY + TEMP (passive) WIRING

OUTDOOR WEATHER HUMIDITY

OVERVIEW

The Tasseron Outdoor Weather Sensors are high quality outdoor relative humidity transmitter in a NEMA 4X / IP65 injection-molded Meteorological Box enclosure. The solar shield provides additional protection from rain and snow while protecting both relative humidity and temperature sensors when installed in areas where sunlight may be present.

The Outdoor Weather Series is available in 2% or 3% RH accuracies with 0-10V analog humidity signal, an active temperature signal plus has ordering options for additional passive thermistors or RTDs.

Circuit boards are coated to resist moisture and dual filters on the sensing elements provide extra protection against environmental conditions. Sensing elements are very accurate with long term stability.

THHOMZ3C OUTDOOR WEATHER HUMIDITY 3% 0-10V NO TEMP THHOMZ2C OUTDOOR WEATHER HUMIDITY 2% 0-10V NO TEMP THHOMR3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + TEMP TR (-10..40C) THHOMR2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + TEMP TR (-10..40C) THHOMA3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 10K-2 TEMP THHOMA2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 10K-2 TEMP THHOMB3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 10K-3 TEMP THHOMB2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 10K-3 TEMP THHOMJ3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 10K-3[11K] TEMP THHOMJ2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 10K-3[11K] TEMP THHOMG3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 10K-4 TEMP THHOMG2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 10K-4 TEMP THHOMC3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 20K TEMP THHOMC2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 20K TEMP THHOMD3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + NTC 3K TEMP THHOMD2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + NTC 3K TEMP THHOME3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + RTD PT1000 TEMP THHOME2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + RTD PT1000 TEMP THHOMH3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + RTD PT100 TEMP THHOMH2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + RTD PT100 TEMP THHOMF3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + RTD NI1000-891 TEMP THHOMF2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + RTD NI1000-891 TEMP THHOMK3C OUTDOOR WEATHER HUMIDITY 3% 0-10V + RTD NI1000-TC5 TEMP THHOMK2C OUTDOOR WEATHER HUMIDITY 2% 0-10V + RTD NI1000-TC5 TEMP

FEATURES

  • Humidity or RH+T analog options available (0-10V or 4-20mA)

  • Durable NEMA 4X/IP65 injection-molded watertight enclosure

  • Quick Connect wire terminals for secure and tool-free wiring

  • Dual element filters to protect from contamination

  • 2% / 3% / 5% RH accuracies available

  • Analog temperature output 0-10V or 4-20mA

  • Additional passive NTC/RTD temperature elements available

  • Coated circuit boards for moisture resistance

  • AISI 316 SS probe

  • CE & RoHS compliant

  • 5 year limited warranty

  • Made in the USA

BUY NOW
BUY NOW
REQUEST A QUOTE
REQUEST A QUOTE
Datasheet
Datasheet

Instructions:

OUTDOOR WEATHER RH INSTALLATION INSTRUCTIONS
